| Processor Core Available | 16 to 40 core, depending on processor |
|---|---|
| Processor Number | 1 or 2 |
| Processor type | Intel® Xeon® Scalable Processors Family |
| Power supply type | Dual hot-plug redundant 1+1 HPE Flexible Slot Power Supplies (2.6”) |
| NVDIMM Capacity | Optional: 128 GB – 512 GB |
| NVDIMM Type | Optional: Intel® Optane™ Persistent Memory for HPE |
| Memory protection features | RAS – Advanced ECC, online spare, mirroring, combined channel (lockstep) functionality, and HPE Fast Fault Tolerant Memory (ADDDC); Intel Optane Persistent Memory |
| Memory slots | 32 |
| Maximum Memory | 8.1 TB – RDIMM (4 TB per processor), 11.2 TB – LRDIMM and Intel® Optane™ (5.6 TB per processor with 8x LRDIMM and 8x 512 GB Intel Optane) |
| Memory Type | HPE DDR4 Smart Memory |
| Form Factor | 2U Rack |
| Expansion Slots | 8, for detailed descriptions refer to the QuickSpecs |
| Optical drive type | Optional DVD-ROM Optional via Universal Media Bay External support only |
| Drive Supported | 8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD, 2 M.2 SATA SSD standard on primary riser, depending on configuration, 8 SFF mid-tray optional, 6 SFF rear drive optional or 4 LFF mid tr |
| System Fan Features | Hot-plug redundant fans, standard |
| Server Controllers | Network controllerIntel I350 1GbE 4 port Base-T OCP3 adapter or Broadcom 57416 10GbE 2 port Base-T adapter and/or optional network adapters depending on model Storage controllerHPE SR932i-p and/or H |
| Security | SecurityOptional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0 |
| Management Software | Infrastructure managementHPE iLO Standard with intelligent provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, and HPE OneView Advanced (optional, requires |
